BSP FLAT SEAT MALE
HF2P-MT – BSPP FSEAT M
11003005
| Hose ID | Termination | Dimensions | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Item Code | Dash | DN | Inch | Dash | Inch | Thread | LC inch | LC mm | LD inch | LD mm | H1 mm | H2 mm |
| 11003005-040400 | -04 | DN 06 | 1/4" | -04 | 1/4" | 1/4" X 19 | 1.04 | 26.3 | - | - | 19 | - |
| 11003005-060600 | -06 | DN 10 | 3/8" | -06 | 3/8" | 3/8" X 19 | 1.09 | 27.8 | - | - | 22 | - |
| 11003005-060800 | -06 | DN 10 | 3/8" | -08 | 1/2" | 1/2" X 14 | 1.23 | 31.3 | - | - | 27 | - |
| 11003005-080800 | -08 | DN 12 | 1/2" | -08 | 1/2" | 1/2" X 14 | 1.26 | 32.1 | - | - | 27 | - |
| 11003005-101000 | -10 | DN 16 | 5/8" | -10 | 5/8" | 5/8" X 14 | 1.42 | 36.1 | - | - | 30 | - |
| 11003005-121200 | -12 | DN 19 | 3/4" | -12 | 3/4" | 3/4" X 14 | 1.44 | 36.6 | - | - | 32 | - |
| 11003005-121600 | -12 | DN 19 | 3/4" | -16 | 1" | 1" X 11 | 1.64 | 41.6 | - | - | 41 | - |
| 11003005-161600 | -16 | DN 25 | 1" | -16 | 1" | 1" X 11 | 1.67 | 42.4 | - | - | 41 | - |
