BSPT MALE
HF2P-MT – BSPT M
ISO 7
11004005
| Hose ID | Termination | Dimensions | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Item Code | Dash | DN | Inch | Dash | Inch | Thread | LC inch | LC mm | LD inch | LD mm | H1 mm | H2 mm |
| 11004005-030200 | -03 | DN 05 | 3/16" | -02 | 1/8" | 1/8" X 28 | 0.86 | 21.8 | - | - | 12 | - |
| 11004005-040200 | -04 | DN 06 | 1/4" | -02 | 1/8" | 1/8" X 28 | 0.88 | 22.3 | - | - | 12 | - |
| 11004005-040400 | -04 | DN 06 | 1/4" | -04 | 1/4" | 1/4" X 19 | 1.06 | 26.8 | - | - | 17 | - |
| 11004005-040600 | -04 | DN 06 | 1/4" | -06 | 3/8" | 3/8" X 19 | 1.11 | 28.3 | - | - | 19 | - |
| 11004005-050400 | -05 | DN 08 | 5/16" | -04 | 1/4" | 1/4" X 19 | 1.06 | 26.8 | - | - | 17 | - |
| 11004005-050600 | -05 | DN 08 | 5/16" | -06 | 3/8" | 3/8" X 19 | 1.11 | 28.3 | - | - | 19 | - |
| 11004005-060400 | -06 | DN 10 | 3/8" | -04 | 1/4" | 1/4" X 19 | 1.06 | 26.8 | - | - | 17 | - |
| 11004005-060600 | -06 | DN 10 | 3/8" | -06 | 3/8" | 3/8" X 19 | 1.11 | 28.3 | - | - | 19 | - |
| 11004005-060800 | -06 | DN 10 | 3/8" | -08 | 1/2" | 1/2" X 14 | 1.31 | 33.3 | - | - | 22 | - |
| 11004005-080600 | -08 | DN 12 | 1/2" | -06 | 3/8" | 3/8" X 19 | 1.15 | 29.1 | - | - | 19 | - |
| 11004005-080800 | -08 | DN 12 | 1/2" | -08 | 1/2" | 1/2" X 14 | 1.34 | 34.1 | - | - | 22 | - |
| 11004005-101200 | -10 | DN 16 | 5/8" | -12 | 3/4" | 3/4" X 14 | 1.38 | 35.1 | - | - | 27 | - |
| 11004005-121200 | -12 | DN 19 | 3/4" | -12 | 3/4" | 3/4" X 14 | 1.40 | 35.6 | - | - | 27 | - |
| 11004005-121600 | -12 | DN 19 | 3/4" | -16 | 1" | 1" X 11 | 1.78 | 45.1 | - | - | 36 | - |
| 11004005-161200 | -16 | DN 25 | 1" | -12 | 3/4" | 3/4" X 14 | 1.47 | 37.4 | - | - | 32 | - |
| 11004005-161600 | -16 | DN 25 | 1" | -16 | 1" | 1" X 11 | 1.81 | 45.9 | - | - | 36 | - |
| 11004005-202000 | -20 | DN 32 | 1.1/4" | -20 | 1.1/4" | 1.1/4" X 11 | 1.99 | 50.5 | - | - | 46 | - |
| 11004005-242400 | -24 | DN 38 | 1.1/2" | -24 | 1.1/2" | 1.1/2" X 11 | 2.03 | 51.5 | - | - | 50 | - |
| 11004005-323200 | -32 | DN 51 | 2" | -32 | 2" | 2" X 11 | 2.24 | 57.0 | - | - | 65 | - |
