PH309 - SEWER JET - 3000 PSI
Construction
Inner tube
Special Polyurethane
Reinforcement
One or more braids of synthetic fiber and one special braid of synthetic fiber armoring
Cover
Polyurethane, Green Colour
Application
Used for sewer cleaning, bonded construction to resist kinking. Resists cuts, abrasion and microbiological degradation. Available in long lengths
| Note : Special colours available on request |
| Item Code |
Dash Size |
DN |
ID
|
OD
|
WP
|
BP
|
BR/r
|
W
|
|||||
| inch | mm | inch | mm | psi | bar | psi | bar | inch | mm | g/m | |||
| PH309-08 | -08 | 12 | 1/2 | 12.7 | 0.890 | 22.6 | 3000 | 210 | 7600 | 525 | 3.3 | 85 | 290 |
| PH309-12 | -12 | 20 | 3/4 | 19.0 | 1.190 | 30.2 | 3000 | 210 | 7600 | 525 | 4.5 | 115 | 490 |
| PH309-16 | -16 | 25 | 1 | 25.4 | 1.475 | 37.5 | 3000 | 210 | 7600 | 525 | 5.9 | 150 | 735 |
| PH309-20 | -20 | 32 | 1.1/4 | 31.8 | 1.830 | 46.5 | 3000 | 210 | 6800 | 475 | 9.3 | 235 | 1160 |
Temperature Range : Continuous: -40°C to +60°C
